EECP-MC2 System Equipment Vasomedical
|
| Selected Ad |
| Category: |
Misc. Equipment |
| Title: |
EECP-MC2 System Equipment Vasomedical |
| Ad
Number: |
1203 |
| Date Posted: |
10/6/2004 |
| Contact: |
Casey Edwards
18201 Von Karman Ave., Ste. 660
Irvine, CA 92612
|
| Telephone: |
949-222-6107
|
| Website: |
http://www.medicalsolutionsgrp.com
|
|
|
|
|
|
Description
FEATURES AND BENEFITS:
• Affords you the confidence in treating your patients with the only external counterpulsation system proven safe and effective in randomized, controlled, double-blinded clinical trials.
• System configuration engineered to maximize therapeautic treatment levels and patient outcomes
• System components ergonomically designed to maximize patient comfort and safety
• Clinical and technical support programs to establish and ensure the success of the treatment facility
SYSTEM CONFIGURATION & PHYSICAL DESCRIPTION
Component H x W x D Weight
Control Console 7 x 16 x 19 (in.) 33 lbs.
18 x 40 x 48 (cm) 15 kg
Control Cabinet 43 x 19 x 22 (in.) 88 lbs.
110 x 49 x 56 (cm) 40 kg
Treatment Table 28 x 36 x 82 (in.) 220 lbs.
70 x 90 x 208 (cm) 100 kg
Compressor Unit (110v) 29 x 16 x 31 (in.) 176 lbs.
74 x 40 x 78 (cm) 80 kg
Compressor Unit (220v) 36 x 19 x 33 (in.) 220 lbs.
93 x 50 x 88 (cm) 100 kg
Power Supply (110v/60hz System):
Control Cabinet and Console: 100-130VAC, 60Hz, 250W (15A or 20A hospital grade outlet)
Compressor: 100-130VAC, 60Hz, 1.8kW (20A hospital grade outlet)
Power Supply (220v/50hz System):
Control Cabinet and Console: 200-250VAC, 50Hz, 250W (15A or 20A hospital grade outlet)
Compressor: 200-250VAC, 50Hz, 2.0kW (15A hospital grade outlet)
Regulatory Approvals:
• US FDA 510(k) Clearance for Marketing
• CE Mark - Notified Body No. 0543
• ETL Listed - Control No. 9901809
• ISO 9001 Certified - Registration No. A6147
Treatment Room Size:
Recommended: 10 ft. x 10 ft. (2.5 x 2.5 meters)
Application Environment:
Temperature: 50-100° F (10-38° C)
Relative Humidity: 30-90%
NOTE: This unit is refurbished and comes with a 1 year warranty and is in excellent working condition
Medical Solutions Group, Inc.
18201 Von Karman Ave., Suite 660
Irvine, CA 92612
949-222-6107
|
|
|
|
|
|
|
|
|
|
