Drager Narkomed 2B Anesthesia Machine
|
| Selected Ad |
| Category: |
Anesthesia |
| Title: |
Drager Narkomed 2B Anesthesia Machine |
| Ad
Number: |
1290 |
| Date Posted: |
12/12/2004 |
| Contact: |
Justin Jeffries
1800 Williamson Court
Louisville, KY 40223
|
| Telephone: |
502-244-4444
|
| Website: |
http://www.dremed.com
|
|
|
|
|
|
Description
1-800-462-8195 The NAD Narkomed 2B is one of their longest running and most reliable model lines. The 2B has O2 and N2O standard with optional medical air and holds 3 vaporizers. An AVE ventilator with F-Style ascending bellows is a standard feature with oxygen, volume & pressure monitoring. Drawer pack configurations may vary from picture. Drager Narkomed 2B Refurbished Process Features and Options Overview: 19.1 and 19.3 vaporizers availableORM standard; ORMC optional Ventilator options: Pneumatic or electronic, ascending or descending bellows Oxygen monitor and CO2 absorber standard AVE Electronic ventilator Absorber and scavenger Oxygen analyzer Breathing pressure monitor Respiratory volume Centralized alarm and data Oxygen ratio controller Pressure limit controller Dimension Specifications Maximum Height: 68" (173cm) Maximum Width: 40" (102cm) Maximum Depth: 25" (63.5cm) Table-top Height: 34" (86cm) Table-top Area: 271 in. sq. (1,749cm2) Shelf Area: 200 in. sq. (1,290cm2) Drawer Dimensions Large: 14"x21"x7" (36x52x18cm) Small: 14"x17"x3" (36x43x8cm) Nominal Weight: 325 lb. (147kg) Electrical Conductivity: The NARKOMED 2B Anesthesia System is equipped with conductive casters. All anesthesia machines are tested for electrical conductivity between one caster as a measuring point and the table-top, shelf-top, and inspiratory valve, alternately, as the other measuring point. The maximum allowable resistance between any two points is 250,000 ohm. Gas Delivery System Information: Standard Gases: The Narkomed 3 is equipped with pneumatic circuitry for the delivery of oxygen (o2) and nitrous oxide (N2O). It has at least on oxygen and one nitrous oxide yoke for reserve gas cylinders with flush-type valves. The Pin Index Safety System prevents connection of a cylinder of the incorrect type. Option Gases: In addition to oxygen and nitrous oxide, the NARKOMED 3 may be equipped with up to two additional gases. The additional gas may be air, helium, (He), nitrogen (N2), or carbon dioxide (CO2). The additional gas may be supplied to the anesthesia system by means of pin-indexed cylinders and yokes, by Diameter Indexed Safety System (DISS) pipeline connections, or by both systems, if so selected. Color Coding: Each connection, valve, gauge, and flowmeter is labeled and color-coded for the appropriate gas, as shown in the following table: GAS LABEL COLOR CODE Air AIR Yellow Carbon Dioxide CO2 Gray Helium He Brown Nitrogen N2 Black Nitrous Oxide N2O Blue Oxygen O2 Green
